XT60 30A Lithium battery connector Female With fixing hole
Order information:
KLS1-XT60-FW-8
Type-XT60
FW-Female With fixing hole
Color 8-Yellow 3-Black
Product model: Female With fixing hole:KLS1-XT60-FW |
Application:Lithium battery / controller / charger |
Product color: Yellow / Black | Metal material: Brass Gold Plated |
Instantaneous current: 60A | Recommended wire gauge: 12 # / 14 # / 16# |
Rated current: 30A | Insulation material: PA66 |
Contact resistance: 0.60m Ω | Operating temperature: – 20 ℃ to 120 ℃ |
Withstand voltage: DC 500V | Plug times:1000 times |
Flame retardant grade: UL94-V0 |
