XT30 15A Controller charger connector Male & Female

  • Model: KLS1-XT30-3P
  • MOQ: 1000 PCS
  • Payment: L/C, D/A, D/P, T/T
  • Place_of_Origin China
  • Delivery_Time: 10 days
  • Product Details

XT30 15A Controller charger connector Male & Female

Order information:
KLS1-XT30-3P-MS-8
Type-XT30
3P-3 Pins
MS-Male Straight  MR-Male Right Angle  FS-Female Straight   FR-Female Right Angle
Color 8-Yellow  3-Black

Product model:
Male: KLS1-XT30-3P-MS
Female Straight: KLS1-XT30-3P-FS
Female Right Angle: KLS1-XT30-3P-FR
Application:Lithium battery / controller / charger
Product color: Yellow / Black Metal material: Brass Gold Plated
Instantaneous current: 30A Recommended wire gauge: 16 # / 18 # / 20#
Rated current: 15A Insulation material: PA66
Contact resistance: 1.20m Ω Operating temperature: – 20 ℃ to 120 ℃
Withstand voltage: DC 500V Plug times:1000 times
Flame retardant grade: UL94-V0
