Features:
Compliant with MSA standard.
Press-fit contact is compliant with IEC60352.
Special design to keep the entrance integrity avoid distortion in shape.

Material:
Body Cage: Copper Alloy with Nickel Plating.
Front EMI Gasket: Stainless Steel
Front flange: Zinc Alloy
Heat sink: Aluninum
Heat sink clip: Stainless Steel
Upper rear EMI gasket: Conductive Form
Lower rear EMI gasket: Conducive Elastomer

Mechanical:
Transceiver Insertion Force: 40 N Max.
Transceiver Extraction Force: 30 N Max.
Durability: 100 Cycles Min.
Operating Temperature Range: -20°C ~+85°C

KLS12-XFP-02.pdf
