Note:
1- Center Contact:Phosphor Bronze, Gold plated
2-Body-diecast: Brass,Ni plated
3-Insulation: PTFE
4-Electrical
Impedance: 50 Ω
Frequency Range:0-300MHz
Voltage Rating: 400 volts
Withstand Voltage:2000V
V.S.W.R:＜1.4
Insulation resistance: 5000 MΩ Min.
5-Mechanical
Mating: 5/8-24 threaded coupling
6-Durability(mating) 500 cycles Max.
7-Temp.range -40°C~85°C
