Material:
1, Insert: H62Y silvered
2, The base: PPA
3, Shrapnel: silver coated copper
4, Party hat head: PPA Black
5 Cover: H62T copper tin

Electrical Characteristics:
Rating: 50mA 12VDC
Contact Resistance : 50mΩ max(initial)
Insulation Resistance: 100MΩ（minDC 250V）
Dielectric Strength : AC250V(50/60Hz for 1minute)
Electrically Life:80,000cycles
Environment temperature: -25℃～105℃
Operating Force: 180/250(±30gf)

KLS7-TS6603T.pdf
