Electrical:
1.Rating:50mA 12V DC
2.Contact Resistance:100mΩ Max.
3.Insulation Resistance:100MΩ Min,100V DC
4.Dielectric voltage proof:250V AC for 1min
5.Electrically Life:100000 cycles Min.
6.Operating Force:250±50gf
7.Environment temperature:-30ºC~+70ºC

Materials:
A.Cards: Copper
B.Pedestal:LCP,Black
C.Shrapnel:Silver coated stainless steel
D.Dust Film:0.05
E.Push button:LCP,Black
F.Cover:Stainless steel

KLS7-TS3465.pdf
