Material
Housing: Thermoplastic
Contacts: copper
Pin Plated: Gold 3u” over 50u” nickel
Shell: Spcc,Nickel plated

Electrical
Contact Current Rating: 1.5 A
Withstanding Voltage:500VAC(Rms)
Contact Resistance: 30mΩ Max
Insulation Resistance:1000MΩ Min

Mechanical
Operating Temperature:-30°C TO +80°C.
