SMD piezo buzzer,Externally driven type

Rated Voltage: 90Vp-p
Operating Voltage: 1-150Vp-p
Rated Current : 80mA Max.
S.P.L.(@10cm): 95dB Min at Rated Voltage at 10cm
Resonance Frequency : 3.5±0.5KHz
Capacitance at 100Hz: 35000±30%pF at 100Hz 1V
Operating Temp: -30~+85°C
Weight: 20g
Housing Material: ABS (Black /Red/ yellow)

Size: Φ54 x 23mm

KLS3-SMT-54x23.pdf
