MECHANICAL :
CAGES: NICKEL SILVER ALLOY, THICKNESS 0.25MM.
CONNECTOR HOUSING: GLASS FILLED PLASTIC, 94 V-0, COLOR: BLACK.
OVERMOLDED TERMINAL HOUSING: GLASS FILLED PLASTIC, 94 V-0, COLOR: BLACK.
LIGHTPIPES: POLYCARBONITE, 94 V-0, COLOR: CLEAR.
LIGHTPIPE HOLDER: GLASS FILLED PLASTIC, 94 V-0, COLOR: BLACK.
CLIP: STAINLESS STEEL.
EMI SPRING: COPPER ALLOY.
TERMINAL: POSPHRR BRONZE.
GOLD PLATING FOR CONTACT AREA, THICKNESS SEE OPTION.
TIN PLATING FOR PRESS FIT AREA.
NICKEL PLATING AS UNDERLAYER FOR WHOLE TERMINAL.

ELECTRICAL :
VOLTAGE: 30 VOLTS AC.
CURRENT: 0.50 A PER CONTACT.
CONTACT RESISTANCE: 50 MILLIOHMS MAX;
INSUL ATION RESISTANCE: 1000 MEGAOHMS MIN AT 100 VDC FOR 1 MINUTE.
DIELECTRIC WITHSTANDING VOLTAGE: 300 VDC MIN;

TEMPERATURE :
OPERATION: -40℃ ~+85℃
STORAGE: – 55℃ ~+105℃
LIGHTPIPE PAD LAYOUT IS FOR LOW-PROFILE LED PACKAGE. LED SIZE(LxWxH): 2x1x0.4MM MAX.
RoHS COMPLIANCE.

KLS12-SFP+07.pdf
