MECHANICAL :
CAGES: NICKEL SILVER ALLOY, THICKNESS 0.25MM.
CONNECTOR HOUSING: GLASS FILLED PLASTIC, 94 V-0, COLOR: BLACK.
OVERMOLDED TERMINAL HOUSING: GLASS FILLED PLASTIC, 94 V-0, COLOR: BLACK.
LIGHTPIPES: POLYCARBONITE, 94 V-0, COLOR: CLEAR.
LIGHTPIPE HOLDER: GLASS FILLED PLASTIC, 94 V-0, COLOR: BLACK.
CLIP: STAINLESS STEEL.
TERMINAL: POSPHRR BRONZE.
GOLD PLATING FOR CONTACT AREA, THICKNESS SEE OPTION.
TIN PLATING FOR PRESS FIT AREA.
NICKEL PLATING AS UNDERLAYER FOR WHOLE TERMINAL.
ELECTRICAL :
CURRENT: 0.50 A PER CONTACT.
CONTACT RESISTANCE: 50 MILLIOHMS MAX;
INSUL ATION RESISTANCE: 1000 MEGAOHMS MIN AT 100 VDC FOR 1 MINUTE;
DIELECTRIC WITHSTANDING VOLTAGE: 300 VDC MIN.
TEMPERATURE :
OPERATION: -40℃ ~+85℃
STORAGE: -40°C ~+85℃
LIGHTPIPE PAD LAYOUT IS FOR LOW-PROFILE LED PACKAGE.
LED SIZE(LxWxH): 2x1x0.4MM MAX. RoHS COMPLIANCE.
