ELECTRICAL :
1.VOLTAGE RATING: 30 VAC;
2.CURRENT RATING: 0.5 A;
3.CONTACT RESISTANCE: 30 MILL IOHMS MAX ;
4.DIEL ECTRIC WITHSTANDING VOLTAGE: 300 VDC MIN ;
5.INSUL ATION RESISTANCE: 1000 MEGAOHMS MIN AT 100 VDC FOR 1 MINUTE.

MATERIAL :
1.HOUSING: LCP UL94V-0 COLOR BALCK ;
2.CONTACT: PHOSPHOR BRONZE T=0.20MM ;
CONTACT PLATING: GOLD PLATING ON CONTACT AREA, OVER NICKEL UNDERPL ATING OVERALL ;
3. ROHS COMPLIANCE ;
4.DURABILITYB 100 CYCLES MIN.

ENVIRONAMENTAL :
1.OPERATION TEMPERATURE RANGE: -40℃ ~+85℃.
2. STORAGE TEMPERATURE RANGE: -40℃ ~+85℃.
3. IR REFLOW PEAK SOLDERING TEMPERATURE: 255°C 10 SECONDS.
4. RoHS COMPLIANT.
