SFP 2×2 Press-Fit Connector
- Product Details
MECHANICAL :
1. CONTACT: PHOSPHOR BRONZE C5210-EH T=0.20mm.
2. CONNECTOR HOUSING: LCP UL 94V-0. COLOR: BLACK.
3. MOULDED INSERT: LCP UL 94V-0. COLOR: BLACK.
4. CAGE: COPPER ALLOY.
C7701 T=0.25mm.
5. LIGHT PIPES: POL YCARBONATE. UL 94V-0. COLOR: CLEAR.
6. LIGHT PIPE HOUSING: PBT+30%.G.F UL 94V-0 COLOR: BLACK.
PLATED :
1. CONTACT AREA: PLATING GOLD 15u”MIN OVER 50~80u”NICKEL.
2. DURABILITY: 100 CYCLES MIN.
3. INSERTION AND EXTRACTION FORCE: 40N MAX & 11 .5N MAX.
ENMIRONMENTAL :
1. LOW LEVEL CONTACT RESITANCE(LLCR):
△R 10 MIL LIOHMS MAXIMUM FOR SHIELD AND SIGNAL CONTACTS.
2. DIELECTRIC WITHSTANDING VOLTAGE: 300V AC/MAX.
3. INSULATION RESISTANCE: 1000MQ MIN.
4. RATINGS CURRENT: 0.5 Amps MAX.
5. RATINGS VOLTAGE: 120 volts AC.
6. OPERATION: -40°C ~+85℃.
7. STORAGE: -55℃ ~+105℃.
8. ROHS COMPLIANT.
