Russia Energy Meter LCD Or Counter type
- Product Details
Description
Single phase meter with KEMA certificate only with kWh measurement. It is widely used in Sub-metering system. The Max. Current could up to 100A.
Technical Parameters
| Voltage: | 110V/220V/230V/240V |
| Current: | 10(100)A |
| Accuracy class: | 1.0 |
| Standard: | IEC62052-11, IEC62053-21 |
| Frequency: | 50Hz/60Hz |
| Impulse constant: | 800imp/kWh/1600imp/kWh/3200imp/kWh/6400imp/kWh |
| Display: | LCD 6+1 / LCD 6+2 |
| Power consumption: | ≤0.3VA ≤6W |
| Starting current: | 0.4%Ib |
| Working Temperature: | -30～70℃ |
| Storage Temperature: | -40～75℃ |
| Average humidity value of year: | ≤75% |
| Meter Size: | 179*120*60mm |
| Net Weight: | 0.4872kg |
