Electrical:
1.Electrical Rating: 6A 250V AC T85
6A 125V 250VAC
2.Circuit Diagram:3P ON-OFF
3.Terminal Strength:≥80N
4.Electrical life:≥10000 Cycles
5.Withstand Voltage:1800VAC 1min
6.Terminals to button:3000VAC 1min
7.Leakage Current:1mA
8.Contact Resistance: ≤50mΩ(initial)
9.Insulation Resistance:≥100MΩ

KLS7-026.pdf
