Technical parameters:
Impedance: 50Ω
Frequency Range:DC～3GHz (50Ω);
Working Voltage:2700V max
Withstand Voltage:4000V rms
Contact resistance:Center Contac:≤0.4 mΩ ;Outer Contact:≤1. 5 mΩ
Insulation resistance:≥ 10000 MΩ
VSWR  Straight:≤ 1.15(0.8-2.5GHZ)
Durability(mating):≥500（cycles）
Temp.range:-55°C～+155°C
Vibration:100m/s2 (10～500Hz)

MATERIAL & PLATING
Shell:Brass,Nickel-plating
Contact pin:Tin brass,silver-plating
Insulator:PTFE
O-ring sealing:6146   silastic
