Electrical :
Rated Voltage:                450V(IEC/EN)/300V(UL)
Rated Current:                9A
Cross Section:                 0.5-1.5mm²/16-20AWG

Materials
Insulation Materials:        PA 66,WHITE,UL94V-2
Contact:                          Copper,Nickel Plated
Wire guard :                    Stainless steel

Number of   poles:             3  poles
Strip length :                 8-10mm
Operating Temperature:    -40°C~+105°C

KLS2-238N-03P.pdf
