Push Switch

  • Model: KLS7-PS-22F08
  • MOQ: 1000 PCS
  • Payment: L/C, D/A, D/P, T/T
  • Place_of_Origin China
  • Delivery_Time: 10 days
  • Product Details

Push Switch
Self-lock and Non-lock
Operating Temperature: -40oC ~ +80oC
Withstand Voltage:AC800V(50Hz)/min
Rated load: 30V DC, 0.3A
Actuating Force:2-8N
Contact Resistance:<0.02Ω
Life:100000 cycles
Insulation Resistance:>500MΩ
