Electrical:
1.Rated load:1.5A 250V AC
2.Contact Resistance:≤50mΩ
3.Insulation Resistance:≥100MΩ
4.Withstand Voltage:500V AC 1minute
5.Actuating Force:750g±50g
6.Electrically Life:≥50000 cycles
7.Environment temperature:-40ºC~+70ºC

Materials:
1. Base: POM
2. Cover:POM
3.Upper teeth:POM
4.Bottom teeth:POM
6.Contact:H65 brass band TM = 0.3mm
7.Horizontal needle:H62 brass band Y1 = 0.28mm

KLS7-KAN8-008.pdf
