Electrical :
Rated Voltage: 250V (IEC/EN)/600V(UL)
Rated Current: 16A
Cross Section(IEC EN/UL)
Solid conductor: 0.75-2.5mm²/14-18AWG
Stranded conductor: 0.75-2.5mm²/14-18AWG
Flexible conductor: 0.75-2.5mm²/14-18AWG

Materials
Insulation Materials: Polyamide 66,Black,UL 94V-2
Contact: Brass,Nickel Plated
Screw: M3, SteelZinc Plated
Number of poles: 3 poles
Strip length : 7mm
Protection Degree: IP30
Operating Temperature: 90°C

KLS2-3240.pdf
