Electrical :
Rated Voltage: 250V IEC/EN
Rated Current: 16A IEC/EN
Cross Section(IEC EN)
Solid conductor: 0.75-1.5mm²
Stranded conductor: 0.75-1.5mm²
Flexible conductor: 0.75-1.5mm²

Materials
Insulation Materials: Polyamide 66,Black,UL 94V-2
Contact: Brass,Nickel Plated
Screw: M3, SteelZinc Plated
Number of poles: 5 poles
Strip length : 7mm
Protection Degree: IP30
Operating Temperature: 90°C

KLS2-3239.pdf
