Order Information
KLS2 – 6211 DS – 12P – 9 S
6211: Pitch 10.0mm with H1.2mm
DS: 囗: Without shrapnel DS: With Shrapnel
12P: Pin Number
9: White Color
S: Slot Serew
Material:
Screw: M3 Steel, any Zinc plated
Terminal: Copper alloy, Ni plated
Housing: PA66, UL94V – 2
Electrical:
Rated Voltage: 450V
Rated current: 24 A
Wire Range: 4 mm²
Mechanical:
Temperature Range: – 30 ℃ ~ + 105 ℃
Strip length: 6.5 mm
