Material:
Screw: M3, Steel,Zn plated
Shrapnel: Stainless steel, Nickel plated
Pin header: Brass , Tin plated
Housing: PA66 , UL94V-0

Electrical:
Rated voltage: 300V
Rated current: 15A
Wire range: 26~14AWG 2.5mm²
Contact Resistance: 20 m Ω
Insulation resistance: 500MΩ/DC500V
Withstand voltage: AC2000V / 1 min

Mechanical:
Temp. Range: -40 ° C ~ + 105 ° C
Soldering: 250° C±5° C for 5S
Torque: 0.5 N.m (4.43Lb. in)
Strip length: 6~7 mm

KLS2-166-5.00.pdf
