Material:
Screw:         M2.5, Steel,Zn plated
Shrapnel:     Stainless steel, Nickel plated
Pin header:  Brass , Tin plated
Housing:      PA66 , UL94V-0

Electrical:
Rated voltage:   300V
Rated current:    15A
Wire range:      26~14AWG  2.5mm²
Contact Resistance: 20 m Ω
Insulation resistance:  500MΩ/DC500V
Withstand voltage:      AC2000V / 1 min

Mechanical:
Temp. Range:   -40 ° C ~ + 105 ° C
Soldering:       250° C±5° C   for   5S
Torque:            0.4 N.m (3.54Lb. in)
Strip length:     6~7 mm

KLS2-168-5.00.pdf
