Material:
Screw:         M2.5, Steel,Zn plated
Shrapnel:     Phosphor bronze, Nickel plated
Pin header:  Brass, Tin plated
Housing:      PA66, UL94V-0

Electrical:
Rated voltage:  250V
Rated current:  16A
Wire range:      22~14AWG  2.5mm²
Contact Resistance: 20 m Ω
Insulation resistance:  500MΩ/DC500V
Withstand voltage:      AC2000V / 1 min

Mechanical:
Temp. Range:   -40 ° C ~ + 105 ° C
Soldering:         250 ° C   5Sec.  Max.
Torque:            0.4 N.m (3.6Lb. in)
Strip length:     4.5~5 mm

KLS2-305V-5.00.pdf
