Material:
Screw:         M2, Steel,Zn plated
Shrapnel:     Phosphor bronze, Nickel plated
Pin header:  Brass, Tin plated
Housing:      PA66 , UL94V-0

Electrical:
Rated voltage:  125V
Rated current:  10A
Wire range:      24~18AWG  1.0mm²
Contact Resistance: 20 m Ω
Insulation resistance:  500MΩ/DC500V
Withstand voltage:      AC2000V / 1 min

Mechanical:
Temp. Range:   -40 ° C ~ + 105 ° C
Soldering:       250° C±5° C   for   5S
Torque:            0.2 N.m (1.77Lb. in)
Strip length:     4.5~5 mm

KLS2-350R-3.50 & 3.96.pdf
