Order Information:
KLS1-204MA-XX-R-口-口
XX-No.of 04~26pin
Color: R=Red B=Black
Material: A=PBT D=PA9T E=PA46
Packing: NONE=Tube R=Reel

Material:
Housing: PBT/PA46 UL94V-0
Contacts: Brass
Plating: Sn over 50u” nickel

Electrical Characteristics:
Current Rating: 1.0 AMP
Contact Resistance: 20m Ohm max.
Insulator Resistance: 1000M Ohm min.
Withstand voltage: 500V AC
Operating Temperature: -40ºC~+105ºC
