Material
Nut and Body Material:         PC
Film:                                    EPTFE
Sealing:                               NBR, EPDM
IP rating:                             IP67
Thread:                                M12*1.5
Panel Mounting:                   ∅12 or M12*1.5
Temp. Range:                       -40 ° C ~ + 125 ° C
breathable valve Range:      1300ml/minute
Maximum torque:                          10Kgf.cm  Max.

KLS1-VA02M1201.pdf
