Material:
Housing:    PC
Flammability Rating : UL94V-2
Contacts:  Phosphor Bronze T=0.50mm
Plating:     TIN Plating

Electrical:
Voltage Rating:           125VAC
Current Rating:           1.5A
Contact Resistance:    30mΩ Max.
Insulation Resistance: 500MΩ Min. at 500V dc
Dielectric Strength:    1000VAC Rms 50Hz,1 Min.
Durability:                  750 cycles Min.
Operation Temperature:-40°C~+85°C

KLS12-CM110-10.pdf
