Material
Housing: 30% Glass filled PBT UL94V-0
Contacts: copper
Pin Plated: Gold 3u” over 50u” nickel
Shell: Spcc,Nickel plated

Electrical
Contact Current Rating: 1.8 A
Withstanding Voltage:500VAC(Rms)
Contact Resistance: 30mΩ Max
Insulation Resistance:1000MΩ Min

Mechanical
Operating Temperature:-30°C TO +80°C.

KLS1-148.pdf
