Order information
KLS15-253-P2      XX

P2:  IP67 Plug male Pin

XX:  Contacts Code

Material:
SHELL Housing:     Brass, Nickel plated
Insert Housing:     PA66+GF 20%
Contact:               Brass,    Silver plated
Termination:          Solder
Locking:               Threaded Coupling
Version:               Straight
Mating life:          500 cycles

IP rating:             IP67
Cable Diameter:   ∅6.0~∅8.5mm
Temperature Range:-25°C ~ + 80°C

KLS15-253-P2.pdf
