Order Information
KLS1-  MW 01  –  010   3000

MW:     GSM+WIFI
Con. Code:   010: SMA-J  Connector
3000:  Cable Lenges

Specification:
GSM Antenna
Frequency Range: 824~2500MHz
V.S.W.R:＜2.0
Polarization:Linear
Gain: 3.0dBi Max.
Impendance:50Ω

Cable:RG58
Connector:SMA/N or others
Radome Material:ABS
Mounting Method:Screw
Operating Temperature :-40℃~+85℃
