1- Center Contact: Brass,Gold-plated
2- Body-diecast: Brass,Nickel-plated
3- Insulation: PTFE
4- Electrical
Impedance: 50 Ω
Frequency Range:0~3 GHz Max.
Voltage Rating: 500 volts
Withstand Voltage:1000V
Insulation Resistance:5000 MΩ
V.S.W.R:＜1.22
Contact resistance:
Centre contact: 10 mΩ Max.
Outer contact: 5 mΩ Max.
5- Mechanical
Mating: Slide-On Push-Pull Threaded
6- Durability(mating):500(cycles)
