Electrical:
Rated voltage: 300V
Rated current:  12A
Contact resistance: 20mΩ
Insulation resistance: 500MΩ/500V
Withstanding Voltage: AC1500V/1Min
Wire range: 22-14AWG 1.5mm²

Material:
Screws: M2.5 steel Zinc plated
Wire guard: phosphor bronze Ni plated or stainless steel
Housing: PA66,UL94V-0

Mechanical:
Temp. Range: -40ºC~+105ºC
MAX Soldering: +250ºC for 5 Sec.
Torque: 0.4Nm (3.6lb.in)
Strip length: 4.5-5mm
