Electrical:
Rated voltage: 300V
Rated current: 10A
Contact resistance: 20mΩ
Insulation resistance: 500MΩ/500V
Withstanding Voltage: AC2000V/1Min
Wire range: 28-16AWG  1.5mm²

Material:
Screws: M2.5 steel Zinc plated
Wire guard: phosphor bronze Ni plated or stainless steel
Housing: PBT,UL94V-0

Mechanical:
Temp. Range: -40ºC~+105ºC
Torque: 0.4Nm (3.5lb.in)
Strip length: 4.5-5mm

KLS2-332K-5.00.pdf
