Electrical:
Rated voltage: 250V
Rated current: 10A
Contact resistance: 20mΩ
Insulation resistance: 5000MΩ/1000V
Withstanding Voltage: AC1500V/1Min
Wire range: 22-14AWG 1.5mm²

Material:
Screws: M2.5 steel Zinc plated
Wire guard: phosphor bronze Ni plated or stainless steel
Housing: polyamide glass filled ,UL94V-0

Mechanical:
Temp. Range: -30ºC~+105ºC
Torque: 0.4Nm (3.6lb.in)
Strip length: 6.0mm

KLS2-331KB-5.00.pdf
