Electrical:
Rated voltage: 300V
Rated current:  8A
Contact resistance: 20mΩ
Insulation resistance: 500MΩ/DC500V
Withstanding Voltage: AC1500V/1Min
Wire range: 28-16AWG 1.5mm²

Material:
Screws: M2 steel Zinc plated
Reed:Phosphor Bronze ,Electroless nickel
Pin header: Brass, Tin plated
Housing: PBT, UL94V-0

Mechanical:
Temp. Range:-40ºC~+105ºC
MAX Soldering: +250ºC for 5 Sec.
Torque: 0.2Nm (1.7 lb.in)
Strip length: 4.5-5mm

KLS2-333K-3.50.pdf
