Order Information
KLS1- GSM18 010 3000

Antenna Frequency :
GSM: 890~960/1710~1880MHz
3G: 824~960/1710~2170MHz
4G: 1710~2650MHz
Con. Code: 010: Standard SMA Connector
3000: Cable Lenges

Specification:
Frequency : GSM: 890~960/1710~1880MHz
3G: 824~960/1710~2170MHz
4G: 1710~2650MHz
Gain : 3dBi
Vswr : 2.0 Max.
Impedance : 50 Ω
Polarization : Linear
Radiation : OMNIDIRECTIONAL
Shell material : ABS
Connector : SMA or Other
Cable: RG174, Black
Length:3000mm or Other
Lightning protection: DC Grounding
Operating Temperature : -30°C to +70°C

KLS1-GSM18.pdf
