Order Information
KLS1- GSM05 010 3000
Antenna Frequency :
GSM: 890~960/1710~1880MHz
3G: 824~960/1710~2170MHz
4G: 1710~2650MHz
Con. Code: 010: Standard SMA Connector
3000: Cable Lenges
Specification:
Frequency : GSM: 890~960/1710~1880MHz
3G: 824~960/1710~2170MHz
4G: 1710~2650MHz
Gain : 3dBi
Vswr : 2.0 Max.
Impedance : 50 Ω
Polarization : Vertical
Radiation : OMNIDIRECTIONAL
Max power : 10W
Shell material : PVC
Size: 21x122mm
Connector : SMA or Other
Cable: RG174, Black
Length:3000mm or Other
Lightning protection: DC Grounding
Operating Temperature : -30°C to +70°C
