Material
Housing: Thermoplastic, Glass Fiber Filled,UL94-HB
Cover: Thermoplastic, Glass Fiber Filled, UL94V-0
USB2.0 Contact: Copper Alloy,Gold.
USB3.0 Contact: Copper Alloy,Gold.
Shell: Brass/Spcc,Nickel(Ni) T=0.30MM

Electrical
Contact Current Rating:1.5 A For
Pin1&Pin4 0.25 A Other Contacts.
Withstanding Voltage:100vac(Rms)
Contact Resistance: 30mΩ Max(Initial) For Pin1&Pin4
                              50mΩ Max(Initial) For Other Contacts
                              10mΩ Max Change For Post Test Llcr
Insulation Resistance:1000mΩ Min

Mechanical
Operating Temperature:-40°C TO +85°C.
Mating Force: 35N MAX
Unmating Force: 10N MIN.

KLS1-148F.pdf
