Material
Housing: Thermoplastic, Glass Fiber Filled,UL94-HB
Cover: Thermoplastic, Glass Fiber Filled, UL94V-0
Contact: Copper Alloy,Gold.
Shell: Brass/Spcc,Nickel(Ni) T=0.30MM

Electrical
Contact Current Rating:     1.5 A For Pin1&Pin4
                                           0.25 A Other Contacts.
Withstanding Voltage:100vac(Rms)
Contact Resistance:   30mΩ Max(Initial) For Pin1&Pin4
                                   50mΩ Max(Initial) For Other Contacts
Insulation Resistance:1000MΩ Min

Mechanical
Operating Temperature:-30°C TO +80°C.
Mating Force: 35N MAX
Unmating Force: 10N MIN.

KLS1-3001.pdf
