Material:
Standard:PBT
Contact: Phosphor Bronze,Au or Sn Over Ni
Insulator:Polyester,UL94V-0

Electrical Characteristics:
Rated Current:3.0AMP
Contact Resistance: 30mΩ Max
Withstand Voltage:1000V  AC/DC
Insulator Resistance: 1000MΩ Min

Mechanical:
Operating Temperature: -40ºC~+105ºC
Max.Processing Temp:180°C for 30-60 seconde
                                       (200°C for 10 seconde)

KLS1-D3C-3264-F.pdf
