MATERAL

Insulator:    PBT  UL94V-0
Shell:          SPCC,Nickel Plated
Contact:      Brass,Tin plated

ELECTRICAL
Contact current Rating:     1 A 100V AC
Dielectric Withstanding:     250V AC 1 min.
Insulation Resistance:       100MΩ Min.
Contact Resistance:          30mΩ Max.

KLS1-157A.pdf
