Material:
Housing:LCP ,UL94V-0 Black.
Contact:Phosphor Bronze,T=0.20±0.01mm.
Front Shell:Stainless Steel,T=0.20±0.01mm.
Back Shell:Stainless Steel,T=0.20±0.01mm.
Clasp:Stainless Steel,T=0.40±0.01mm.
Finishes:
Contacts: Gold flashed,on Contact area.
               100u-120u” Tin.Plating, on solder tails.
               50u-80u” Nickel,Underplating over all.

Electrical:
Current Rating:1A Max.
Dielectric Withstanding Voltage:
             500 VAC far Minute.
Contact Resistance:30mΩ Max.
Insulation Resistance:1000MΩ Min at DC 500V.
Temperature Range:-55°C TO +105°C.

KLS1-235-3.pdf
