Material
Housing:LCP,UL94V-0,Black.
Contact:Copper Alloy.
Shell:SUS 304 T=0.20.

Finish:
Contact:Gold Plating on Contact area.
        80u” Sn Plating on solder tail area.
        50u” Min.Nickel Under plating over all.

Electrical:
Voltage Rating:30VAC RMS.
Current Rating:2.0A(pin 1 5);
                      1.0A(pin 2 3 4).
Contact Resistance:50mΩ Max.
Insulation Resistance:100MΩ Min.
Dielectric Withstanding Voltage:
               500 V AC For 1 Minute.
Operating Life:5000 cycles.
Operating Temperature: -20℃~+85℃
