Material
Housing:Hing Temperature Thermoplastic
            with g.f,UL94V-0.
Contact:Copper Alloy,t=0.20mm.
Shell:SUS,t=0.20mm.

Electrical:
Current Rating:1A Max.
Dielectric Withstanding Voltage:
                    100 V AC for 1 min.
Contact Resistance:50mΩ Max.
Insulation Resistance:100MΩ Min.
Total Mating Force:3.57 kgf Max.
Total Unmating Force:1.0 kgf Min.
Temperature Range:
                   -30°C Up To +80°C

KLS1-236-5M6.pdf
