Material:
Housing:LCP E130,UL94V-0 Black
Contact:Brass 5210.
Shell:Stainless Steel,T=0.20±0.03mm.

Plating:
Contact:Plated Gold Flash For Contact Area.
Shell:Nickel Over All (salt spray for 24H).
Shell:Gold Over All (salt spray for 24H).

Electrical:
Operating Temperature:-20°C TO +80°C.
Product Compliant to the request RoHS

KLS1-235-5.pdf
