NOTES:
1.Current Current Rating:1.0A(Signal PIN 2 3 4);
                                         1.8A (Power PIN 1 5)
2.Contact Resistance:40mΩ Max.
3.Insulation Resistance:100MΩ Min.
4.Dielectric Withstanding:100 V AC Min.
5.Durability:10000 cycles.
6.Connector Mating forces:35N Max (3.57Kgf).
7.Connector Unmating force:8N Min (0.30Kgf).
8.Product Meet The Request of the RoHS
