1- Electrical
    Impedance: 50 Ω
    Frequency Range:0~4 GHz Max.
    Voltage Rating: 500 volts
    Withstand Voltage:1500V
    Insulation Resistance:5000 MΩ
    V.S.W.R:＜1.22
    Contact resistance:
      Centre contact: 1.5 mΩ Max.
      Outer contact:  0.2  mΩ Max.
2- Durability(mating):500(cycles)
3- Mechanical
   Mating 2-stud bayonet lock

Cable Type: RG174, RG178,RG316,LMR100
