Electrical:
Voltage Rating AC 125V
Current Rating 1.5 AMPS
Insulation Resistance 500 MΩ Min
Withstand Voltage DC 1000V RMS 50-60Hz 1Min
Contact Resistance 20MΩ MAX

Mechanical:
Insertion Force 2 pins 3.5N      4pins 5N 6 pins 7.5N   8pins  9N
Retention Strength 70N between jack and plug 60 N between wire and IDC
Durability Jack 700 mating cycles mini IDC contact 100 stripper cycles mini
Wire AWG 24-26

Working Environmental:
Temperature -10°c~+60°c
Humidity 10~90%

KLS12-DK8018.pdf
