Material:
Housing:PBT+30%GF,UL94V-0.
Shell:Brass C2680 T=0.30mm ,Plated Nickel
Terminal:Phosphor Bronze  C5191 T=0.25mm,
             Plated Gold/Tin.

Electrical:
Voltage Current Rating:1.5AMP,30V AC.
Insulator Resistance:1000MΩ Min.
Contact Resistance:30mΩ Max.
Withstanding Voltage:500V AC

Mechanical
Operating Temperature:-55°C TO +85°C.
Mating Force:3.5kgf MAX.
Unmating Force:1.0kgf MIN.

KLS1-18R1.pdf
